aluminium tilting regenerative melting furnace
Model: melting furnace
|
|
Regenerative Aluminum Melting furnace
Aluminum melting furnace introduction
Brightstar aluminum Machinery take the air preheater regenerative burner technology that is widely used in the fields for aluminum melting furnace, preheating the air temperature to reach more than 800oC, exhaust gas temperature below 150 oC, achieving the highly thermal efficiency, low fuel consumption, low CO2/NOx emission. This technology is successful and reliable, safe and stable operation, easy and convenient maintenance. In addition, this air preheater regenerative melting furnace compare with the non regenerative melting furnace, there is 30% energy saving effect.
Aluminum melting furnace technical parameter and features
1) The use of furnace: melting and heat preservation of the aluminum profile.
2).The furnace is wrapped by armor plate and profiled bar.
3) Melting pool adopt the first-degree aluminum brick;the outer adopt lightweight heat preservation brick.
4).the loading: 10-100 tons/furnace(aluminum water)
5).the out size of furnace: length?width?height=5000?4050?6200
6) the structure form is tilted furnace door vault and square furnace.
7) fuel: heavy oil,gas and LPG
8) burning capacity: 300kg/h (max) ?
9) burning consumption: 50-70kg/T•AL
10) melting rate: 3~4t/h?
11) the air warm-up temperature: 1100oC?
12) eliminate mist temperature: ?200oC?
13) burning type: one coupe muzzle burning by turns.
14) control type: PLC (automatic or manual) ?
15) the furnace side temperature: room temperature+45oC
|
|
